Product SKU: DEA-900-E-BOX-6
In Stock
Freight Delivery
Kit Price:
$3,195.00
$4,262.00
Cantilever gates aren’t only contemporary and modern in appearance, besides cantilever design automatic sliding gates are the ideal choice for anyone with uneven ground, paving that is organic in shape, and gravel driveways. Cantilever gate designs are frequently used as no track work needs to be installed. This makes cantilever gates an option for surfaces that are inappropriate for track gates.
A cantilever gate needs to be about 35% wider than its span to counterbalance the weight of the suspension posts.
The installations do not require complicated steps and materials, so the working time is not too long. We invite you to follow the below installation steps of CAIS "ALL IN ONE" cantilever sliding gate hardware.
Single cantilever gates move in one direction, often directly parallel to an existing fence line. This efficient use of space makes a cantilever gate an ideal choice when designing a property’s perimeter fence and security system.
We have to ensure that all the gate hardware that you need to assemble the cantilever sliding gate is included.
See what the "ALL IN ONE" box includes:
Carriage for cantilever gates with up to 8 meters clear opening & 700 kg max gate weight.
Enhanced design and superior products from Europe using high-quality German steel.
Formed from high-quality, heavily galvanized German steel in an 18-stage process with a slow rolling speed to reduce heat build-up and memory.
"C" Profile Guide For Cantilever Sliding Gate, 5mm Hot Deepped Thickness, Galvanized German Steel
Enhanced design and superior products from Europe using high-quality German steel.
Formed from high-quality, heavily galvanized German steel in an 18-stage process with a slow rolling speed to reduce heat build-up and memory
Bolts and Rivet Nuts are Included in each Cantilever "C" Profile Guide
The end wheel guides the gate onto the end cup and helps support the gate while it rests.
Cantilever Gate Hardware Medium Guide Support Wheel
The end cap is an addition to the gate to cap off the cantilevered track.
Cantilever Gate Hardware Medium End Cap
The end stop supports the gate when fully open and closed.
Cantilever Gate Hardware Medium End Stop
The end stop bracket supports the gate when it is fully open and fully closed.
Cantilever Gate Hardware End Stop Bracket
Two Roller overhead guide brackets and roller assemblies for Gates of up to 160mm wide.
40mm x 30mm Rollers & Bracket. Suitable as a guiding system for manual or automatic sliding gates. The bracket supplied can be mounted on walls, pillars, posts, and other supports to withstand the load.
Rollers: 67mm x 40mm Rollers
Bracket: L shape mounting bracket 260mm x 130mm.
Reliable, Track-Free Gate Systems for Australian Homes and Businesses
A cantilever sliding gate operates without a track on the ground. Instead, it uses cantilever sliding gate hardware, including rollers, brackets, and Cantilever Carriage Wheels that support the gate above the surface. This makes it ideal for Australian properties with gravel or non-concrete driveways. Cantilever sliding gates can handle uneven terrain. Whether its a gravel driveway, grassy area, or even waterlogged ground, cantilever gates remain functional
| Feature | Traditional Sliding Gate | Cantilever Sliding Gate |
|---|---|---|
| Operation | Moves along a ground track | Suspended; glides above ground |
| Surface Compatibility | Flat, level, concrete surface | Gravel, pavers, gradients, grass |
| Hardware | Track + bottom wheels, rollers and post brackets | Top-mounted rollers and post brackets, carriage wheels, channels |
| Weather Resistance | The track can clog with debris | Performs well in all weather |
| Installation | Requires ground excavation | Manageable installation |
Cantilever gates are widely used across Australia from suburban homes in Melbourne and Sydney to commercial sites in Brisbane, Perth, and Adelaide. Whether you're in a coastal region or rural setting, this hardware is designed to perform reliably under Australian conditions.
Selecting the right gate system is crucial for achieving long-term performance and maintaining property value. Cantilever sliding gate hardware is the preferred solution for Australians seeking a durable, stylish, and easy-to-install gate system that can handle Australias diverse terrains and weather.
Looking for premium cantilever gate hardware kits in Australia? Contact us today to learn more or request a quote.
The sliding gate opener DEA-900 is an extra heavy-duty all-metal gear that has full programmability using the onboard control board with an LCD interface. It has a capacity of 10m and 900 kg, and is suitable for residential usage with simple setups and commercial sites and a suitable sliding gate on sloped driveways. See the full details below.
| Motor power supply (V) | 230 - 240 V ~ (50/60 Hz) |
| Motor power supply voltage (V) | 24 V |
| Maximum Power (W) | 110 |
| Max thrust (N) | 260 |
| Duty cycle (cycles/hour) Gate L=5 metres |
18 |
| N. max cycles in 24h. Gate L=5 metres |
40 |
| Leaf max weight (kg) | 900 |
| Operating temperature (°C) | -20÷50 °C |
| Speed (m/min) | 10 |
| Standard pinion | Z=16 (m=4mm) |
| Weight with packing (Kg) | 12 |
| Sound pressure (dBA) | < 70 |
| Protection level | IP44 |
A- Column with photocell
B -Operator
C- Photocells
D -Safety edge
E- Flashing light
F- Keyswitch / Digikey
G- Junction box
Nylon gate rack with a steel core for screwing to your sliding gate rail to allow the gate motor to act. Compatible with sliding gate and cantilever gate systems.
The fastening system, "Three Points", on the six rack attachments (in this model, facing upward, opposite the teeth) guarantees a higher capacity than the prior models, up to a maximum of 800 KG.
The material used is always a polyamide, 30% fibreglass but elastomeric, to guarantee great performance even in very cold environments.
Nylon sliding gate rack used for both domestic and commercial sliding and cantilever gate systems. Up to 800kg with 10×10 steel core to the centre. There are six brackets up mounting lugs with a 25mm gap in-between, allowing for adjustability in case of ground movement over time.
The benefit of brackets up is that they allow greater reach to the motor gears when the gate's bottom beam is positioned higher than the motor.
The six bracing lugs allow for a higher load capacity on the rack at 800kg.
| Application | Screw on the lengths of the gear rack to enable the sliding gate to move when actuated. |
| Material | Nylon Coated with Steel Core |
| Capacity | 800KG |
| Country of Manufacture | Italy |
24v - 2x12v 1.2Ah rechargeable battery kit, complete with cables. (Pre-installed when purchased with the Gate Opener Kits)
Battery Backup Kit For
DEA 600kg / 900kg / 1400kg Sliding Gate Kit Technical Features | Battery charger for DEA Sliding Gate Automation.
Power line supply:
16vac … 24vac
Operating temperature:
-20°C +55°C
Maximum input power:
15W
Lead-acid batteries:
2 x 12vdc 1200mAh
Nominal charge voltage:
27.6 Vdc
Minimum self-protection voltage of the battery:
19.5 Vdc
